McIntosh C52 User Manual

11
How to use the HR085 Remote Control
How to use the Remote Control
The supplied C52 Remote Control (HR085) is capable
of directly controlling the functions of contemporary
McIntosh Source Components connected to the C52
via the Data Ports.
Notes: 1. If at any time the C52 seems unresponsive to
the HR085 Remote Control Commands, press
the DEVICE Push-button to select
first.
2. For additional information on using the
HR085 Remote Control with the McIntosh
Model, please refer to the “How to Operate”
starting on page 20.
3. For additional information on assigning the
Data Ports, refer to “How to Setup” on page
16.
Trim
Press the TRIM Push-button until the desired Trim
function (Balance, Trim Level, etc.) appears on the
C52 Front Panel Display, then press the LEVEL Up or
Down Push-button to adjust the Trim setting.
Note: Press the TRIM Push-button to recall the last Trim
function selected. For additional information on
using the Trim Functions refer to “How to Oper-
ate” page 20.
Output Selection
Press the BLUE (Setup) Push-button followed by
the AM (Output 1) or FM (Output 2) Push-button, to
control the Rear Panel Audio OUTPUTS 1, 2 (ON or
OFF) and Power Control TRIG 1 / TRIG 2.
Note: For additional information on assigning the Out-
puts (1 and 2) and Power Control Triggers (1 and
2) refer to page 16.

McIntosh C52 Specifications

General

Type	Solid State Preamplifier
Total Harmonic Distortion	0.005%
S/N Ratio	100dB
Digital USB Input	1
Digital Coaxial Input	2
Digital Optical Input	2
Digital MCT Input	1
Home Theater PassThru	Yes
Signal to Noise Ratio	100dB
Power Consumption	50 watts
Dimensions	17-1/2 inches (44.5 cm) wide, 6 inches (15.2 cm) high (including feet), 18 inches (45.7 cm) deep (including front panel and cables)
High Level Inputs	8
Phono Inputs	1 Moving Magnet, 1 Moving Coil
Headphone Output	Yes
Gain	15dB
Frequency Response	+0, -0.5dB from 20Hz to 20kHz
