McIntosh MC207

C35 CAP ELECT 10UF 100VDC 066462
C36 CAP ELECT 10UF 100VDC 066462
C37 CAP ELECT 10UF 100VDC 066462
C38 CAP ELECT 10UF 100VDC 066462
C40 CAP ELECT 220UF 50V 20% 066254
C41 CAP ELECT 10UF 100VDC 066462
C47 CAP POLYPROP .047UF 10% 250VDC
064364
C51 CAP ELECT 10UF 100VDC 066462
C200 CAP ELECT 10UF 100VDC 066462
D1 DIODE SILICON 070047
D2 DIODE SILICON 070047
D4 DIODE SILICON 070047
D5 DIODE SILICON 070047
D6 DIODE RECTIFIER 070131
D7 DIODE RECTIFIER 070131
IC2 IC DUAL AMP 133259
J1 CONN MALE 9 POS FRICTION LOCK
117244
J2 CONN 4 PIN 117215
J4 CONN HEADER 2 PIN 0.156 117404
J5 BLADE FASTON .110 117712
J6 BLADE FASTON W/FEET 117708
J8 CONN HEADER 2 PIN 0.156 117404
J9 CONN 2 PIN MALE 117213
K1 RELAY 24VDC 5A 277VAC 087057
K2 RELAY 24VDC 5A 277VAC 087057
L2 CHOKE 0.65UH OUTPUT 122297
LD1 LDR NETWORK VTL5C9 144179
Q1 TRANSISTOR NPN 132223
Q2 TRANSISTOR PNP 132224
Q3 TRANSISTOR NPN 132268
Q4 TRANSISTOR PNP 132267
Q5 TRANSISTOR NPN 132223
Q6 TRANSISTOR NPN 25C3334C 132285
Q7 TRANSISTOR PNP 2SA32IC 132286
Q8 TRANSISTOR PNP POWER 132297
Q9 TRANSISTOR NPN POWER 132296
Q10 TRANSISTOR PNP POWER 132297
Q11 TRANSISTOR NPN POWER 132296
Q20 TRANSISTOR NPN POWER 132296
Q22 TRANSISTOR PNP POWER 132297
Q23 TRANSISTOR NPN POWER 132296
Q25 TRANSISTOR PNP POWER 132297
Q27 TRANSISTOR PNP 132224
Q29 TRANSISTOR PNP POWER 132255
Q30 TRANSISTOR SI NPN 25V 132254
Q31 TRANSISTOR NPN 132223
Q32 TRANSISTOR NPN 132223
Q33 TRANSISTOR PNP POWER 132255
Q35 TRANSISTOR NPN 132223
Q37 TRANSISTOR NPN 25C3334C 132285
Q39 TRANSISTOR PNP 2SA32IC 132286
Q41 TRANSISTOR PNP 132224
Q49 TRANSISTOR PNP 132224
Q50 TRANSISTOR NPN 132223
Q51 TRANSISTOR NPN 132223
Q52 TRANSISTOR NPN 132223
Q53 TRANSISTOR PNP POWER 132255
Q54 TRANSISTOR PNP 132224
Q55 TRANSISTOR PNP POWER 132255
Q56 TRANSISTOR PNP POWER 132255
Q59 TRANSISTOR NPN 132223
Q60 TRANSISTOR SI NPN 25V 132254
Q61 TRANSISTOR SI NPN 25V 132254
Q63 TRANSISTOR NPN 132223
Q64 TRANSISTOR PNP POWER 132255
R1 RES MF 332 OHM 1% 1/4W 144446
R2 RES MET OX 680 OHM 5% .5W
137093
R3 RES MF 22.1K 1% 1/4W 144187
R4 RES MF 100K 1% 1/4W 144113
R5 RES MF 22.1K 1% 1/4W 144187
R6 RES MET OX 1.8k 5% .5W 137094
R7 RES MET OX 430 OHM 5% .5W
137095
R8 RES MF 332 OHM 1% 1/4W 144446
R9 RES MET OX 680 OHM 5% .5W
137093
R10 RES MF 22.1K 1% 1/4W 144187
R11 RES MET OX 1.8k 5% .5W 137094
R12 RES MET OX 47 OHM 5% .5W
137096
R13 POT TRIM 200 OHM 20% HORIZ AD
134390
R14 RES MF 100K 1% 1/4W 144113
R15 RES MF 100 OHM 1% 1/4W 144196
R16 RES MF 100 OHM 1% 1/4W 144196
R17 RES MF 100 OHM 1% 1/4W 144196
R30 RES MF 475K 1% 1/4W 144364
R32 RES MF 47.5K 1% 1/4W 144108
R33 RES MF 47.5K 1% 1/4W 144108
R34 RES MF 5.11K 1% 1/4W 144083
R36 RES 511 OHM 1% 1/4W 144123
R37 RES MF 681K 1% 1/4W 144443
R38 RES MF 866 OHM 1% 1/4W 144028
R39 RES MF 2.21 OHM 1/4W 1% 144378
R41 RES WW DUAL .47 OHM 5% 3W
139244
R42 RES WW DUAL .47 OHM 5% 3W
139244
R43 RES WW DUAL .47 OHM 5% 3W
139244
R45 RES WW DUAL .47 OHM 5% 3W
139244
R46 RES MF 4.75K 1% 1/4W 144097
PARTS LIST con’t
38
4A
4B
4B
