McIntosh MC3500 User Manual

14
Amplier Specications
Power Output
350 watts into 2 ohm load
350 watts into 4 ohm load
350 watts into 8 ohm load
Rated Power Band
20Hz to 20,000Hz
Dynamic Headroom
2.4dB
Wide Band Damping Factor
Greater than 25
Frequency Response
+0, -0.5dB from 20Hz to 20,000Hz
+0, -3.0dB from 10Hz to 70,000Hz
Total Harmonic Distortion
0.3% maximum harmonic distortion at any power level
from 250 milliwatts to rated power, 20Hz to 20,000Hz
Intermodulation Distortion
0.3% maximum, if the instantaneous peak power output
does not exceed twice the rated power output for any
combination of frequencies from 20Hz to 20,000Hz
Signal To Noise Ratio (A Weighted)
120dB below rated output
Input Sensitivity (for rated output)
3.8 Volts Balanced
1.9 Volts Unbalanced
Volt age Gain
29dB, 8 Ohms
26dB, 4 Ohms
23dB, 2 Ohms
Input Impedance
22,000 ohms Balanced
22,000 ohms Unbalanced
General Specications
Power Control Input
5-15VDC, less than 1mA
Power Control Output
12VDC, 25mA (Delayed 0.2 seconds from power on)
Power Requirements
100 Volts ~ 50/60Hz at 7.2 Amps
110 Volts ~ 50/60Hz at 6.0 Amps
120 Volts ~ 50/60Hz at 6.0 Amps
127 Volts ~ 50/60Hz at 6.0 Amps
220 Volts ~ 50/60Hz at 3.3 Amps
230 Volts ~ 50/60Hz at 3.3 Amps
240 Volts ~ 50/60Hz at 3.3 Amps
Standby, less than 0.5 watt
Refer to the rear panel of the MC3500 for the correct
voltage.
Overall Dimensions
Depth is 21-5/8 inches (54.9cm)
Width is 18 inches (45.7cm)
Height is 11-13/16 inches (30cm)
Weight
121 pounds (54.9kg) net
147 pounds (66.7kg) in shipping carton
Shipping Carton Dimensions
Depth is 31 inches (78.7cm)
Width is 28 inches (71.1cm)
Height is 17-1/4 inches (43.8cm)

McIntosh MC3500 Specifications

General

Input Sensitivity	0.5V
Signal to Noise Ratio	105dB
Input Impedance	100k ohms
Power Output	350 Watts
Frequency Response	20Hz to 20kHz
Total Harmonic Distortion	0.5%
Dimensions	Width 17-1/2 inches (44.5 cm) Height 10-1/2 inches (26.7 cm) Depth 20 inches (50.8 cm) including connectors
Output Impedance	4, 8, 16 ohms
