Packing Instructions Packaging Parts List
Qty Description
1 034105 Shipping carton top
1 034104 Shipping carton bottom
3 034678 Foam Ring
1 034705 Tube Foam
In the event it is necessary to repack the equipment
for shipment, the equipment must be packed exactly
as shown below.
It is very important that the four feet are
attached to the bottom of the unit� This will
ensure the proper equipment location on the
bottom pad� Failure to do this will result in
shipping damage�
Use the original shipping carton and interior parts
only if they are all in good serviceable condition.
If a shipping carton or any of the interior part(s)
are needed, please call or write Customer Service
Department of McIntosh Laboratory. Refer to page
Packaging Parts List for the
correct part numbers.
POLY BAG
TOP / BOTTOM
PAD
TOP / BOTTOM
PAD
CARTON TOP
FOAM RING (3)
UNIT WITH
(4) FEET ON
BOTTOM COVER
CARTON BOTTOM
TUBE FOAM
USE BANDING
STRAPS AS
SHOWN
SEAL WITH
PACKAGING TAPE
IMPORTANT
(Read Above)
POLY BAG
TOP / BOTTOM
PAD
TOP / BOTTOM
PAD
CARTON TOP
FOAM RING (3)
UNIT WITH
(4) FEET ON
BOTTOM COVER
CARTON BOTTOM
TUBE FOAM
USE BANDING
STRAPS AS
SHOWN
SEAL WITH
PACKAGING TAPE
IMPORTANT
(Read Above)
