Remote Control Programming
The MS300 remote is a “Universal Remote” which can control up to eight different
components including four MS300 Music Servers. The
MS1, MS2, MS3, and MS4 keys are used to control MS300
Music Servers while the TV, CBL, RCV, and DVD keys
can be setup to control other devices.
Controlling One or More MS300s
The MS1, MS2, MS3, and MS4 keys can be programmed
to control multiple MS300 Music Servers. This feature is
also useful for controlling multiple MS300s located at the
same physical location or on the same IR distribution
system.
There are two steps to controlling multiple MS300 Music
Servers:
1. Setup the remote to transmit the corresponding code
bank
2. Setup the MS300 to receive or listen for a specific
code bank.
Setting up the remote to transmit one of the four code banks
is as easy as pressing the MS1, MS2, MS3, or MS4 keys.
Pressing one of these keys selects the one of the four
MS300 code banks. Next you need to tell each MS300
which bank you want it to listen to. All MS300s ship from
the factory assigned to listen for codes on the MS1 code
bank.
Follow these steps to control a MS300 on the MS2 code
bank.
1. Press the MS1 key on the remote to control a
MS300 on the default bank.
2. Press the SETUP key to display the Setup Menu.
3. Select the External Control Menu.
4. Select the IR & Serial Menu.
5. Select the IR Remote Control Menu.
6. Select the MS2 radio button to tell the MS300 to
listen to the MS2 code bank.
7. Select the SAVE button on the screen.
8. You will be instructed to press the MS2 key on the
remote, then select the OK button.
You have set the MS300 to listen to the MS2 code bank. Repeat these steps to tell the
MS300 to respond and listen to any of the four code banks.
