McIntosh MX132

50
General Specifications
General Specifications cont
Dolby Digital Left, Center, Right Small speakers:
and DTS 80Hz-20,000Hz
Surround Small speakers:
80Hz-20,000Hz
Subwoofer:
20Hz-80Hz
Left, Center, Right Large speakers:
20Hz-20,000Hz
Surround Large speakers:
20Hz-20,000Hz
Subwoofer:
20Hz-80Hz
External Input Left, Center, Right, Left Surround,
Right Surround:
20Hz-20,000Hz
Subwoofer:
20Hz-120Hz
Rated Output
All Modes: 2.0VRMS for full bit digital input
Input Impedance
22K ohms
Output Impedance
47 ohms at all outputs
Maximum Output Voltage
9.5 VRMS
Total Harmonic Distortion
0.005% at all outputs
Sensitivity
Analog Input: 400mV for 2.0V output
Signal To Noise Ratio - All Outputs
Greater than 90dB un-weighted
Greater than 100dB A weighted
Greater than 98dB CCIR
Maximum Input Signal
Analog Input: 6Vrms
Voltage Gain
Analog Input to Output: 14dB
Frequency Response
+0, -0.5dB from 20Hz to 20,000Hz
Tone Controls
+12dB, -12dB from flat setting
Audio Specifications, cont
Power Requirements
100 Volts, 50/60Hz at 65 watts
110 Volts, 50/60Hz at 65 watts
120 Volts, 50/60Hz at 65 watts
220 Volts, 50/60Hz at 65 watts
230 Volts, 50/60Hz at 65 watts
240 Volts, 50/60Hz at 65 watts
NOTE: Refer to the rear panel of the MX132 for the correct
voltage.
Dimensions
Front Panel: 17/1/2 inches (44.5cm) wide, 7-1/16 inches
(17.9cm) high. Depth behind front mounting panel is 21
inches (53.3cm) including clearance for connectors. Panel
clearance required in front of mounting panel is 1-1/8
inches (2.9cm).
Weight
32.5 pounds (14.8Kg) net, 53.5 pounds (24.5Kg) shipping
