McIntosh MX136

14
How to Connect Digital Audio Components
How to Connect Digital Audio Components
1. Connect a cable from the MX136 DIGITAL COAXIAL
AUDIO VIDEO INPUT (Input F) to the McIntosh Co-
axial Digital Output of the McIntosh AUDIO VIDEO
Player.
2. Connect a cable from the MX136 SAT INPUT (Input
B) OPTICAL DIGITAL INPUT to the Optical Digital
Output of a Satellite Receiver.
3. Connect a cable from the MX136 LV INPUT (Input C)
OPTICAL DIGITAL INPUT to the Optical Digital
Output of a Digital Audio Recorder.
4. Connect a cable from the Digital Audio Recorder Input
to the MX136 OPTICAL DIGITAL OUTPUT.
McIntosh Audio Video Player
Digital IN
Digital OUT
Digital Audio Recorder
Satellite Receiver
