SimStep Manual - 3400 Iss. D 7
th
June 2004 page 9
JOG A and JOG B GREEN
Connector type: 15 way 'D’ socket
Compatible with JC100, JC400 and JC809 manual controls
Terminal Connection
1 Jog Common (~+24V)
2 0V
3 Jog + Input
4 Jog – Input
5 Jog Fast Input
6
7
8
9 Joystick Supply (+5V)
10 Joystick Input
11
12 Joystick Centre Tap Input
13
14 Data A
15 Data B
RS232 IN
Connector type: 9 way 'D' type socket
Terminal RS232 Connection RS485 Connection
1 RS485-A
2 Transmit Data
3 Receive Data
4
5 0V
6 RS485-B
7 CTS
8 RTS
9
RS232 OUT
Connector type: 9 way 'D' type plug
Terminal RS232 Connection RS485 Connection
1 RS485-A
2 Receive Data
3 Transmit Data
Link to echo replies
and commands
4
5 0V
6 RS485-B
7 RTS
8 CTS
Link to echo replies
and commands
9
