Mclennan SimStep - 2 External Interface Connections

SimStep Manual - 3400 Iss. D 7
th
June 2004 page 7
2 External Interface Connections
MAINS supply
Connector type: IEC chassis plug
Terminal Connection
L Live input 115/230V AC
(Internally selectable)
N Neutral input
E
Earth. THIS UNIT MUST BE EARTHED
MOTOR
Connector type: HAN-4A socket
Mating Cable: 507MOCxx892 (xx = length)
Terminal Connection
1 Motor Phase A+
2 Motor Phase A-
3 Motor Phase B+
4 Motor Phase B-
E Screen
LIMITS/DATUM RED
Connector type: 15 way ‘D’ Plug
Mating Cable: 507LDCxx894 (xx = length)
Terminal Connection
1
2 0V
3 Upper Limit Input -
4 Lower Limit Input -
5 Datum Approach Input -
6 Datum Stop Input -
7 Abort Stop – (selected by internal link LK8)
8
9
10 Upper Limit Input + (24V)
11 Lower Limit Input + (24V)
12 Datum Approach Input + (24V)
13 Datum Stop Input + (24V)
14 Abort Stop + (24V)
15
Link pins 3 and 10 to enable positive moves
Link pins 4 and 11 to enable negative moves
Link pins 5 and 12 for fast datum search
If external ‘Abort Stop’ selected, link pins 7 and 14 to enable moves.
