adaptor/sockets
The sockets may have
male or female threaded
ends.
Such sockets are useful
to adapt connection with
a steel pipe or tank.
union
locking nut the two halves of the
union
Similar to the steel and copper versions, these unions enable easy connection and dismantling of
two PVC pipe ends.
The PVC pipes are joined to the two halves by using solvent cement and then they are
assembled together with the locking nut.
reducer
Section: 3 Page 39
