The following data are extracted from the mini chiller technical manual:
Water flowrate Velocity, fps
Model
USGPM ft
3
/min 1-1/4" 1"
AC 40A
6.7 0.89 1.43 2.47
AC 50A
8.9 1.19 1.91 3.30
AC 58A
11.1 1.48 2.38 4.12
AC 75B
17.8 2.37 3.80 6.59
AC100B
22.2 2.97 4.75
8.24
AC125B
27.7 3.71 5.94
10.30
AC80C
17.5 2.34 3.75 6.50
AC100C
20.8 2.78 4.46 7.72
AC120C
26.7 3.57 5.72
9.92
AC150C
31.7 4.24 6.79
11.78
It is not recommended
to install these units
with 1” pipe size.
