McQuay AGZ 065A Installation And Operation Manual

IOM 686 AGZ 030A through 065A 17
Table 11, AGZ030A - 065A, 60 Hz, Compressor and Condenser Fan Motor Amp Draw
Rated Load Amps Locked Rotor Amps
AGZ Compressors No. Of Compressors
Unit Volts No. No. Fan Fan Fan Across-The-Line
Size 1 & 3 2 & 4 Motors Motors Motors No.1 & 3 No.2 & 4
(Each) (Each) (Each) (Each) (Each) (Each)
208 22.9 29.9 4.0 4 17.0 169 232
230 22.9 29.9 4.0 4 17.0 189 232
030AS 380 14.9 18.6 3.4 4 14.4 112 144
030AE 460 12.5 15.3 2.0 4 8.5 94 116
575 9.1 11.6 2.2 4 10.3 74 97
208 29.9 29.9 4.0 4 17.0 232 232
230 29.9 29.9 4.0 4 17.0 232 232
035AS 380 18.6 18.6 3.4 4 14.4 144 144
460 15.3 15.3 2.0 4 8.5 116 116
575 11.6 11.6 2.2 4 10.3 97 97
208 33.6 33.6 4.0 4 17.0 255 255
230 33.6 33.6 4.0 4 17.0 255 255
040AS 380 22.8 22.8 3.4 4 14.4 151 151
040AE 460 16.4 16.4 2.0 4 8.5 127 127
575 13.7 13.7 2.2 4 10.3 100 100
208 33.6 39.5 5.8 4 23.7 255 318
230 33.6 39.5 5.8 4 23.7 255 318
045AS 380 22.8 28.2 3.4 4 14.4 151 188
460 16.4 19.3 2.8 4 10.7 127 158
575 13.7 17.3 2.3 4 11.5 100 125
208 39.5 39.5 5.8 4 23.7 318 318
230 39.5 39.5 5.8 4 23.7 318 318
050AS 380 28.2 28.2 3.4 4 14.4 188 188
050AE 460 19.3 19.3 2.8 4 10.7 158 158
575 17.3 17.3 2.3 4 11.5 125 125
208 39.5 52.6 5.8 4 23.7 318 411
230 39.5 52.6 5.8 4 23.7 318 411
055AS 380 28.2 34.6 3.4 4 14.4 188 249
460 19.3 23.7 2.8 4 10.7 158 187
575 17.3 19.0 2.3 4 11.5 125 150
208 52.6 52.6 5.8 4 23.7 411 411
230 52.6 52.6 5.8 4 23.7 411 411
060AS 380 34.6 34.6 3.4 4 14.4 249 249
460 23.7 23.7 2.8 4 10.7 187 187
575 19.0 19.0 2.3 4 11.5 150 150
208 52.6 52.6 5.8 4 23.7 411 411
230 52.6 52.6 5.8 4 23.7 411 411
065AS 380 34.6 34.6 3.4 4 14.4 249 249
460 23.7 23.7 2.8 4 10.7 187 187
575 19.0 19.0 2.3 4 11.5 150 150
Table 12, AGZ030A - 065A, 60 Hz Single Point Power, Field Wiring Data
Wiring to Standard Wiring to Optional
AGZ Power Block Non-Fused Disconnect Switch
Unit Volts Terminal Connector Wire Range Terminal Connector Wire Range
Size Amps (Copper Wire Only) Amps (Copper Wire Only)
208 175 #12 - 2/0 225 # 3 - 300 MCM
230 175 #12 - 2/0 225 # 3 - 300 MCM
030AS 380 175 #12 - 2/0 100 #14 - 1/0
030AE 460 175 #12 - 2/0 100 #14 - 1/0
575 175 #12 - 2/0 100 #14 - 1/0
208 175 #12 - 2/0 225 # 3 - 300 MCM
230 175 #12 - 2/0 225 # 3 - 300 MCM
035AS 380 175 #12 - 2/0 100 #14 - 1/0
460 175 #12 - 2/0 100 #14 - 1/0
575 175 #12 - 2/0 100 #14 - 1/0
208 175 #12 - 2/0 225 # 3 - 300 MCM
230 175 #12 - 2/0 225 # 3 - 300 MCM
040AS 380 175 #12 - 2/0 150 #4 - 4/0
040AE 460 175 #12 - 2/0 100 #14 - 1/0
575 175 #12 - 2/0 100 #14 - 1/0
208 335 # 4 - 400 MCM 225 # 3 - 300 MCM
230 335 # 4 - 400 MCM 225 # 3 - 300 MCM
045AS 380 175 #12 - 2/0 150 #4 - 4/0
460 175 #12 - 2/0 100 #14 - 1/0
575 175 #12 - 2/0 100 #14 - 1/0
Table continued on next page
