McQuay ALR 032E

IM 676 19
Table 13, 032E - 070E Electrical Data Single Point
Minimum POWER SUPPLY FIELD FUSE SIZE
ALR Circuit Field Wire Hub
Unit Volts HZ. Ampacity Wire Nominal Recommended Maximum
Size (MCA) Quantity Gauge Quantity Size
208 151 3 2/0 1 1.50 (38) 175 200
230 151 3 2/0 1 1.50 (38) 175 200
032E 460 60 76 3 4 1 1.00 (25) 90 100
575 58 3 6 1 1.00 (25) 70 80
208 151 3 2/0 1 1.50 (38) 175 200
230 151 3 2/0 1 1.50 (38) 175 200
035E 460 60 76 3 4 1 1.00 (25) 90 100
575 61 3 6 1 1.00 (25) 70 80
208 183 3 3/0 1 2.00 (51) 225 250
230 183 3 3/0 1 2.00 (51) 225 250
040E 460 60 92 3 3 1 1.25 (32) 110 125
575 79 3 4 1 1.00 (25) 90 100
208 217 3 4/0 1 2.00 (51) 250 300
230 217 3 4/0 1 2.00 (51) 250 300
045E 460 60 108 3 2 1 1.25 (32) 125 150
575 89 3 3 1 1.25 (32) 110 125
208 228 3 4/0 1 2.00 (51) 300 300
230 228 3 4/0 1 2.00 (51) 300 300
050E 460 60 113 3 2 1 1.25 (32) 150 150
575 94 3 3 1 1.25 (32) 110 125
208 238 3 250 1 2.50 (64) 300 300
230 238 3 250 1 2.50 (64) 300 300
055E 460 60 118 3 1 1 1.25 (32) 150 150
575 94 3 3 1 1.25 (32) 110 125
208 270 3 300 1 2.50 (64) 350 350
230 259 3 300 1 2.50 (64) 300 350
060E 460 60 134 3 1/0 1 1.50 (51) 175 175
575 102 3 2 1 1.25 (32) 125 125
208 296 3 350 1 2.50 (64) 350 400
230 276 3 300 1 2.50 (64) 350 350
065E 460 60 147 3 1/0 1 1.50 (38) 175 200
575 108 3 2 1 1.25 (32) 125 150
208 322 3 400 1 3.00 (76) 400 450
230 303 3 350 1 2.50 (64) 350 400
070E 460 60 156 3 2/0 1 1.50 (38) 200 200
575 120 3 1 1 1.25 (32) 150 150
208 344 3 500 1 3.00 (76) 400 450
230 326 3 400 1 3.00 (76) 400 450
075E 460 60 164 3 2/0 1 1.50 (38) 200 225
575 130 3 1 1 1.25 (32) 150 175
See page 33 for all Electrical Data notes.
