McQuay ALR 032E

20 IM 676
Table 14, 080E - 135E Electrical Data Single Point
Minimum POWER SUPPLY FIELD FUSE SIZE
ALR Circuit Field Wire Hub
Unit Volts HZ. Ampacity Wire Nominal Recommended Maximum
Size (MCA) Quantity Gauge Quantity Size
208 355 3 500 1 3.00 (76) 400 400
230 355 3 500 1 3.00 (76) 400 400
080E 460 60 177 3 3/0 1 2.00 (51) 200 200
575 154 3 2/0 1 1.50 (51) 175 175
208 368 3 500 1 3.00 (76) 400 450
230 368 3 500 1 3.00 (76) 400 450
085E 460 60 184 3 3/0 1 2.00 (51) 200 225
575 160 3 2/0 1 1.50 (51) 175 175
208 402 6 250 1 3.00 (76) 450 450
230 402 6 250 1 3.00 (76) 450 450
090E 460 60 200 3 3/0 1 2.00 (51) 225 225
575 165 3 2/0 1 1.50 (51) 200 200
208 424 6 300 1 4.00 (102) 450 500
230 424 6 300 1 4.00 (102) 450 500
100E 460 60 210 3 4/0 1 2.00 (51) 225 250
575 175 3 2/0 1 1.50 (51) 200 200
208 494 6 350 1 4.00 (102) 600 600
230 483 6 350 1 4.00 (102) 600 500
110E 460 60 244 3 250 1 2.50 (64) 300 300
575 184 3 3/0 1 2.00 (51) 200 225
208 547 6 500 1 4.00 (102) 600 600
230 517 6 400 1 4.00 (102) 600 600
120E 460 60 270 3 300 1 2.50 (64) 300 300
575 196 3 3/0 1 2.00 (51) 225 225
208 584 6 500 1 4.00 (102) 700 700
230 546 6 500 1 4.00 (102) 600 600
130E 460 60 289 3 350 1 2.50 (64) 300 300
575 206 3 4/0 1 2.00 (51) 225 225
208 615 6 350 2 2.50 (64) 700 700
230 579 6 350 2 2.50 (64) 700 700
135E 460 60 298 3 350 1 2.50 (64) 350 350
575 220 3 300 1 2.00 (51) 250 250
See page 33 for all Electrical Data notes.
