McQuay ALR 032E

30 IM 676
Table 25, 080E - 135E Field Wiring Data ,Single Point Power
Wiring to Wiring to
ALR Standard Power Block Optional Disconnect Switch
Unit Volts HZ. Terminal Connector Wire Range Terminal Connector Wire Range
Size Amps (Copper Wire Only) Amps (Copper Wire Only)
208 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
080E 460 60 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
085E 460 60 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
090E 460 60 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
100E 460 60 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
110E 460 60 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
230 840 (2 qty.) 1/0 - 600 MCM 600 (2 qty.) 250 - 500 MCM
120E 460 60 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
130E 460 60 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
135E 460 60 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
575 335 (1 qty.) #4 - 400 MCM 250 (1qty.) #4 - 350 MCM
See page 33 for all Electrical Data notes.
