IM 676 31
Table 26, 140E - 185E Field Wiring Data, Single Point Power
Wiring to Wiring to
ALR Standard Power Block Optional Disconnect Switch
Unit Volts HZ. Terminal Connector Wire Range Terminal Connector Wire Range
Size Amps (Copper Wire Only) Amps (Copper Wire Only)
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
140E 460 60 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
575 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (2 qty.) 1/0 - 600 MCM N/A
230 840 (2 qty.) 1/0 - 600 MCM N/A
145E 460 60 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
575 335 (1 qty.) #4 - 400 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (4 qty.) 1/0 - 600 MCM N/A
230 840 (4 qty.) 1/0 - 600 MCM N/A
150E 460 60 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
575 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (*) (4 qty.) 1/0 - 600 MCM N/A
230 840 (*) (4 qty.) 1/0 - 600 MCM N/A
160E 460 60 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
575 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (*) (4 qty.) 1/0 - 600 MCM N/A
230 840 (*) (4 qty.) 1/0 - 600 MCM N/A
170E 460 60 840 (2 qty.) 1/0 - 600 MCM 600 (1 qty.) 250 - 500 MCM
575 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (*) (4 qty.) 1/0 - 600 MCM N/A
230 840 (*) (4 qty.) 1/0 - 600 MCM N/A
180E 460 60 840 (2 qty.) 1/0 - 600 MCM 600 (1 qty.) 250 - 500 MCM
575 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
208 840 (*) (4 qty.) 1/0 - 600 MCM N/A
230 840 (*) (4 qty.) 1/0 - 600 MCM N/A
185E 460 60 840 (2 qty.) 1/0 - 600 MCM 600 (1 qty.) 250 - 500 MCM
575 840 (2 qty.) 1/0 - 600 MCM 400 (1 qty.) 250 - 500 MCM
* There are 2 power blocks, each having 840 terminal amps. (1680 total terminal amps)
See page 33 for all other Electrical Data notes.
