22 IOMM ACZ/AGZ-1
Electrical Data AGZ-AM
Electrical Data ACZ
Table 11, AGZ-030AM - 050AM, ACZ 030A - 055A,
60 Hz, Single Point Power Electrical Data
POWER SUPPLY
Field Wire Hub
ACZ
Unit Size
AGZ-AM
Unit Size
Volts
Minimum
Circuit
Ampacity
(MCA)
Quantity
Wire
Gauge
Quantity
Nominal
Size
Max. Fuse
or
HACR
Breaker
Size
208 143 3 1/0 1 1.50 (38) 150
230 143 3 1/0 1 1.50 (38) 150
380 93 3 3 1 1.25 (32) 110
460 73 3 4 1 1.00 (25) 80
035AM
575 58 3 6 1 1.00 (25) 70
208 159 3 2/0 1 1.50 (38) 175
230 159 3 2/0 1 1.50 (38) 175
380 111 3 2 1 1.25 (32) 125
460 78 3 4 1 1.00 (25) 90
045A 040AM
575 67 3 4 1 1.00 (25) 80
208 183 3 3/0 1 2.00 (51) 200
230 183 3 3/0 1 2.00 (51) 200
380 116 3 1 1 1.25 (32) 125
460 94 3 3 1 1.25 (32) 110
050A 045AM
575 76 3 4 1 1.00 (25) 90
208 198 3 3/0 1 2.00 (51) 225
230 198 3 3/0 1 2.00 (51) 225
380 120 3 1 1 1.25 (32) 125
460 104 3 2 1 1.25 (32) 125
055A 050AM
575 83 3 4 1 1.00 (25) 100
All Electrical Data notes are on page 23
Table 12, AGZ-AM, ACZ A, 60 Hz, Compressor & Condenser Fan Motor Amp Draw
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line
ACZ
Unit
Size
AGZ-AM
Unit
Size
Volts
No.
1 & 3
(Each)
No.
2 & 4
(Each)
Fan
Motors
(Each)
No. Of
Fan
Motors
Fan
Motors
(Each)
No.1 & 3
(Each)
No.2 & 4
(Each)
208 29.9 29.9 4.0 4 17.0 232 232
230 29.9 29.9 4.0 4 17.0 232 232
380 18.6 18.6 3.4 4 14.4 144 144
460 15.3 15.3 2.0 4 8.5 125 125
035AM
575 11.6 11.6 2.2 4 10.3 100 100
208 33.6 33.6 4.0 4 17.0 255 255
230 33.6 33.6 4.0 4 17.0 255 255
380 22.8 22.8 3.4 4 14.4 151 151
460 16.5 16.5 2.0 4 8.5 127 127
045A 040AM
575 13.7 13.7 2.2 4 10.3 100 100
208 33.6 41.0 5.8 4 23.7 255 318
230 33.6 41.0 5.8 4 23.7 255 318
380 22.8 25.0 3.4 4 14.4 151 195
460 16.5 21.8 2.8 4 10.7 127 158
050A 045AM
575 13.7 17.3 2.3 4 11.5 100 125
208 41.0 41.0 5.8 4 23.7 318 318
230 41.0 41.0 5.8 4 23.7 318 318
380 25.0 25.0 3.4 4 14.4 195 195
460 21.8 21.8 2.8 4 10.7 158 158
055A 050AM
575 17.3 17.3 2.3 4 11.5 125 125
All Electrical Data notes are on page 23
