5.3.2.5.1 Defrost Sensor
Select [Defrost Sensor] in [Display Menu] and press ENTER to go into this menu.
User can view the defrost sensor temperature for each compressor in the Chiller.
Press [ESC] to exit to [Display Menu]
5.3.2.5.2 Discharge Sensor
Select [Discharge Sensor] in [Display Menu] and press ENTER to go into this menu.
User can view the discharge sensor temperature for each compressor in the Chiller.
Press [ESC] to exit to [Display Menu].
5.3.2.5.3 Comp Run Time
Select [Comp Run Time] in [Display Menu] and press ENTER to go into this menu.
User can view the compressor run time for each compressor in the Chiller. Beside that, user can
clear each compressor run time in this menu. User needs to key in the correct password before
clearing the compressor run time.
Press [ESC] to exit to [Display Menu].
5.3.2.5.4 Inverter Chiller
Select [Inverter Chiller] in [Display Menu] and press ENTER to go into this menu.
This menu display compressor frequency, EXV opening, DC voltage, Current, Suction Sensor,
BPHE in sensor, BPHE out sensor and condenser in sensor.
Press [ESC] to exit to [Display Menu].
20
Defrost Sensor
Comp 1 : 12.8°C
Discharge Sensor
Comp 1 : 36.5°C
Comp Run Time
Comp 1 : 13579h
Suction : 13.3°C
BPHE in : 6.0°C
BPHE out : 12.9°C
Condenser : 43.0°C
Inverter Chiller
Comp. Freq : 100Hz
Exv. : 180
Comp. Amp : 11.0A
DC Bus : 516V
To Next Page
