McQuay M5ACV 030 CR User Manual

Model : M5ACV075CR - Cooling
63
WATER AVAIL. PUMP PUMP
COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING FLOW HEAD INPUT INPUT
CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT RATE PRESS. POWER AMP
kW kW A kW kW A kW kW A kW kW A
m
3
/hr
kPa W A
4 22.22 6.43 11.8 21.80 6.57 12.0 20.83 7.25 13.3 19.94 7.65 14.0 2.86 250 706 1.2
5 23.07 6.53 12.0 22.66 6.67 12.2 21.81 7.38 13.5 20.99 7.79 14.3 3.08 238 724 1.3
6 23.78 6.63 12.2 23.38 6.77 12.4 22.62 7.50 13.7 21.87 7.92 14.5 3.27 228 739 1.3
7 24.34 6.72 12.3 23.95 6.88 12.6 23.28 7.62 14.0 22.58 8.05 14.8 3.41 220 750 1.3
8 24.76 6.83 12.5 24.38 6.98 12.8 23.78 7.73 14.2 23.12 8.18 15.0 3.51 213 756 1.3
9 25.04 6.93 12.7 24.67 7.08 13.0 24.12 7.85 14.4 23.48 8.30 15.2 3.58 209 759 1.3
10 25.42 7.04 12.9 25.05 7.19 13.2 24.51 7.96 14.6 23.87 8.42 15.4 3.65 205 762 1.3
WATER AVAIL. PUMP PUMP
COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING FLOW HEAD INPUT INPUT
CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT RATE PRESS. POWER AMP
kW kW A kW kW A kW kW A kW kW A
m
3
/hr
kPa W A
4 19.28 7.92 14.5 18.55 8.18 15.0 17.35 8.58 15.7 15.06 9.22 16.9 2.86 250 706 1.2
5 20.39 8.06 14.8 19.72 8.34 15.3 18.63 8.74 16.0 16.54 9.40 17.2 3.08 238 724 1.3
6 21.31 8.21 15.0 20.70 8.48 15.6 19.69 8.90 16.3 17.75 9.57 17.6 3.27 228 739 1.3
7 22.05 8.34 15.3 21.48 8.63 15.8 20.52 9.05 16.6 18.67 9.74 17.9 3.41 220 750 1.3
8 22.61 8.47 15.5 22.06 8.77 16.1 21.13 9.20 16.9 19.33 9.91 18.2 3.51 213 756 1.3
9 22.99 8.60 15.8 22.44 8.90 16.3 21.52 9.34 17.1 19.71 10.07 18.5 3.58 209 759 1.3
10 23.38 8.73 16.0 22.83 9.03 16.6 21.91 9.48 17.4 20.11 10.22 18.7 3.65 205 762 1.3
WATER AVAIL. PUMP PUMP
COOL POWER RUNNING COOL POWER RUNNING FLOW HEAD INPUT INPUT
CAP. INPUT CURRENT CAP. INPUT CURRENT RATE PRESS. POWER AMP
kW kW A kW kW A
m
3
/hr
kPa W A
4 14.04 9.48 17.4 11.83 9.98 18.3 2.86 250 706 1.2
5 15.61 9.66 17.7 13.59 10.17 18.7 3.08 238 724 1.3
6 16.88 9.84 18.0 15.00 10.36 19.0 3.27 228 739 1.3
7 17.85 10.01 18.4 16.05 10.55 19.4 3.41 220 750 1.3
8 18.52 10.19 18.7 16.75 10.74 19.7 3.51 213 756 1.3
9 18.89 10.35 19.0 17.09 10.92 20.0 3.58 209 759 1.3
10 19.30 10.52 19.3 17.51 11.10 20.4 3.65 205 762 1.3
LEAVING WATER TEMP (°C
19 20 25
AMBIENT TEMPERATURE ON CONDENSOR (°C)
28
LEAVING WATER TEMP (°C
)
LEAVING WATER TEMP (°C
42 46
30 32
AMBIENT TEMPERATURE ON CONDENSOR (°C)
AMBIENT TEMPERATURE ON CONDENSOR (°C)
35 40
MODEL
M5ACV075CR
MODEL
M5ACV075CR
MODEL
M5ACV075CR

McQuay M5ACV 030 CR Specifications

General

Brand	McQuay
Model	M5ACV 030 CR
Category	Chiller
Language	English
