McQuay M5ACV 030 CR User Manual

Model : M5ACV100 / 135CR - Cooling
64
WATER AVAIL. PUMP PUMP
COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING FLOW HEAD INPUT INPUT
CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT RATE PRESS. POWER AMP
kW kW A kW kW A kW kW A kW kW A
m
3
/hr
kPa W A
4 30.76 8.99 18.3 30.29 9.15 18.6 27.91 9.93 20.2 26.48 10.40 21.1 3.98 218 951 1.8
5 31.84 9.05 18.4 31.48 9.20 18.7 29.14 10.04 20.4 27.73 10.57 21.5 4.25 203 975 1.9
6 32.68 9.09 18.5 32.33 9.26 18.8 30.00 10.16 20.7 28.60 10.72 21.8 4.40 195 987 1.9
7 34.00 9.15 18.6 33.88 9.32 18.9 31.59 10.27 20.9 30.22 10.91 22.2 4.79 173 1013 1.9
8 34.36 9.18 18.7 34.01 9.38 19.1 31.71 10.40 21.1 30.33 11.03 22.4 4.83 170 1015 2.0
9 35.20 9.23 18.8 34.85 9.44 19.2 32.57 10.52 21.4 31.20 11.19 22.7 4.86 168 1017 2.0
10 35.80 9.27 18.8 35.34 9.50 19.3 33.06 10.64 21.6 31.69 11.33 23.0 4.90 166 1019 2.0
4 42.58 11.80 22.4 41.93 12.01 22.8 38.64 13.04 24.8 36.66 13.65 25.9 5.51 203 820 1.8
5 44.08 11.87 22.5 43.58 12.08 22.9 40.34 13.18 25.0 38.39 13.87 26.3 5.89 191 841 1.9
6 45.24 11.93 22.7 44.75 12.16 23.1 41.52 13.34 25.3 39.59 14.08 26.7 6.10 184 853 1.9
7 47.07 12.01 22.8 46.90 12.23 23.2 43.74 13.48 25.6 41.84 14.31 27.2 6.63 165 882 2.0
8 47.57 12.05 22.9 47.08 12.31 23.4 43.90 13.65 25.9 41.99 14.48 27.5 6.68 163 884 2.0
9 48.73 12.11 23.0 48.25 12.38 23.5 45.09 13.80 26.2 43.19 14.68 27.9 6.73 161 887 2.0
10 49.56 12.16 23.1 48.92 12.46 23.7 45.76 13.97 26.5 43.87 14.87 28.2 6.78 159 890 2.0
WATER AVAIL. PUMP PUMP
COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING COOL POWER RUNNING FLOW HEAD INPUT INPUT
CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT CAP. INPUT CURRENT RATE PRESS. POWER AMP
kW kW A kW kW A kW kW A kW kW A
m
3
/hr
kPa W A
4 25.53 10.72 21.8 24.58 11.03 22.4 23.16 11.50 23.4 20.78 12.28 25.0 3.98 218 951 1.8
5 26.79 10.92 22.2 25.85 11.27 22.9 24.72 11.73 23.9 22.10 12.67 25.8 4.25 203 975 1.9
6 27.66 11.10 22.6 26.73 11.47 23.3 25.61 11.98 24.4 23.00 12.97 26.4 4.40 195 987 1.9
7 29.31 11.33 23.0 28.39 11.76 23.9 27.84 12.00 24.4 24.74 13.46 27.4 4.79 173 1013 1.9
8 29.41 11.46 23.3 28.49 11.88 24.1 28.06 12.49 25.4 24.81 13.57 27.6 4.83 170 1015 2.0
9 30.29 11.63 23.6 29.37 12.08 24.6 28.28 12.74 25.9 25.72 13.87 28.2 4.86 168 1017 2.0
10 30.78 11.78 24.0 29.86 12.24 24.9 28.49 12.93 26.3 26.21 14.07 28.6 4.90 166 1019 2.0
4 35.35 14.06 26.7 34.03 14.47 27.5 32.05 15.09 28.7 28.76 16.12 30.6 5.51 203 820 1.8
5 37.09 14.33 27.2 35.79 14.79 28.1 34.22 15.40 29.3 30.59 16.64 31.6 5.89 191 841 1.9
6 38.30 14.57 27.7 37.01 15.06 28.6 35.45 15.73 29.9 31.84 17.03 32.3 6.10 184 853 1.9
7 40.57 14.87 28.2 39.31 15.43 29.3 38.54 15.75 30.0 34.25 17.66 33.5 6.63 165 882 2.0
8 40.72 15.04 28.6 39.44 15.59 29.6 38.84 16.39 31.2 34.35 17.81 33.8 6.68 163 884 2.0
9 41.93 15.27 29.0 40.66 15.86 30.1 39.14 16.72 31.8 35.60 18.20 34.6 6.73 161 887 2.0
10 42.60 15.47 29.4 41.34 16.07 30.5 39.44 16.97 32.3 36.28 18.47 35.1 6.78 159 890 2.0
WATER AVAIL. PUMP PUMP
COOL POWER RUNNING COOL POWER RUNNING FLOW HEAD INPUT INPUT
CAP. INPUT CURRENT CAP. INPUT CURRENT RATE PRESS. POWER AMP
kW kW A kW kW A
m
3
/hr
kPa W A
4 19.83 12.59 25.6 17.93 13.22 26.9 3.98 218 951 1.8
5 21.16 13.02 26.5 19.12 14.21 28.9 4.25 203 975 1.9
6 22.07 13.35 27.1 20.04 14.48 29.4 4.40 195 987 1.9
7 23.82 13.88 28.2 21.51 14.97 30.4 4.79 173 1013 1.9
8 23.89 13.99 28.4 21.89 15.02 30.5 4.83 170 1015 2.0
9 24.81 14.32 29.1 22.82 15.29 31.1 4.86 168 1017 2.0
10 25.30 14.53 29.5 23.47 15.45 31.4 4.90 166 1019 2.0
4 27.45 16.53 31.4 24.82 17.35 33.0 5.51 203 820 1.8
5 29.29 17.09 32.5 26.47 18.64 35.4 5.89 191 841 1.9
6 30.55 17.52 33.3 27.75 19.00 36.1 6.10 184 853 1.9
7 32.98 18.22 34.6 29.78 19.65 37.3 6.63 165 882 2.0
8 33.08 18.37 34.9 30.31 19.71 37.4 6.68 163 884 2.0
9 34.34 18.79 35.7 31.59 20.07 38.1 6.73 161 887 2.0
10 35.02 19.07 36.2 32.49 20.27 38.5 6.78 159 890 2.0
LEAVING WATER TEMP (°C)
19 20 25
AMBIENT TEMPERATURE ON CONDENSOR (°C)
28
LEAVING WATER TEMP (°C
)
LEAVING WATER TEMP (°C
42 46
30 32
AMBIENT TEMPERATURE ON CONDENSOR (°C)
AMBIENT TEMPERATURE ON CONDENSOR (°C)
35 40
M5ACV135CR
MODEL
M5ACV100CR
MODEL
M5ACV100CR
MODEL
M5ACV100CR
M5ACV135CR
M5ACV135CR

McQuay M5ACV 030 CR Specifications

General

Brand	McQuay
Model	M5ACV 030 CR
Category	Chiller
Language	English
