McQuay MCW200DA User Manual

16
MODEL MCW200DA MCW300DA MCW400DA MCW500DA MCW600DA
MCW800DA
CLASS B
MOTOR
MOTOR 1
YDK36-4Be
M03034065200
YSK56-4B4
M03034065201
YSK71-4B4
M03034065202
YSK100-4B4
M03034065203
YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
MOTOR 2 \ \ \ \ \
YDK71-4B4
M03034065205
DRAIN PAN M50014063363 M50014063364 M50014063365 M50014063366 M50014063367
M50014063368
BLOWER
LEFT M03029000980 M03024060001 M03029000980 M03029000980 M03029000980
M03029000980
RIGHT \ M03024060002 M03029000981 M03029000981 M03029000981
M03029000981
COIL
LEFT HAND M50024065190 M50024065191 M50024065192 M50024065193 M50024065194
M50024065195
RIGHT HAND M50024065180 M50024065181 M50024065182 M50024065183 M50024065184
M50024065185
FILTER
8mm NYLON M03084066197 M03084066198 M03084066199 M03084066200 M03084066201
M03084066202
25mm NYLON
M03084066187 M03084066188 M03084066189 M03084066190 M03084066191
M03084066192
MODEL
MCW900DA MCW1000DA
MCW1200DA MCW1400DA MCW1600DA
CLASS B
MOTOR
MOTOR 1
YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
YSK240-4B8
M03034065206
YSK280-4B8
M03034065208
YSK240-4B8
M03034065206
MOTOR 2
YSK150-4B6
M03034065204
YSK150-4B6
M03034065204
YDK95-4B6
M03034065207
YDK125-4B6
M03034065209
YSK240-4B8
M03034065206
DRAIN PAN
M50014063369
M50014063370
M50014063368 M50014063369 M50014063797
BLOWER
LEFT
M03024060001
M03029000980
M03024060003 M03024060003 M03024060003
RIGHT
M03024060002
M03029000981
M03024060004 M03024060004 M03024060004
COIL
LEFT HAND
M50024065196
M50024065197
M50024065202 M50024065203 M50024065204
RIGHT HAND
M50024065186
M50024065187
M50024065199 M50024065200 M50024065201
FILTER
8mm NYLON
M03084066203
M03084066226
M03084066204 M03084066205 M03084066206
25mm NYLON
M03084066193
M03084066225
M03084066148 M03084066195 M03084066196
NOTE:
LEFT OR RIGHT HAND COIL IS CONSIDERED FACING THE AIR FLOW.
