Air Flow vs ESP Table
NOTES:
1) AIR FLOW IS IN DRY COIL CONDITIONS.
2) ESP OUT OF THE RANGE 40-100PA APPLICATION IS NOT RECOMMENDED.
3) FOR MORE AIR FLOW UNDER DIFFERENT CONDITION,PLEASE REFER TO THE SELECTION PROGRAM.
Model fan speed
Air ow(m
3
/h) at ESP(Pa)
40 50 60 70 75 80 90 100
200DA
H 468 436 402 367 349 330 292 253
M 437 400 362 324 304 285 245 205
L 316 285 253 218 201 182 145 105
300DA
H 624 578 529 475 446 417 355 289
M 581 535 484 429 400 370 306 239
L 434 388 342 295 271 247 198 148
400DA
H 858 809 755 696 665 633 566 494
M 794 748 697 642 612 581 515 445
L 595 558 516 470 446 421 367 309
500DA
H 1018 970 918 861 831 800 734 664
M 977 931 880 824 795 764 700 631
L 774 742 703 657 632 605 546 480
600DA
H 1167 1106 1038 963 923 882 794 699
M 1104 1044 978 906 869 830 748 660
L 865 828 782 726 694 660 585 501
800DA
H 1662 1587 1506 1417 1369 1320 1216 1104
M 1592 1516 1433 1344 1296 1247 1144 1033
L 1318 1263 1200 1129 1090 1049 961 865
900DA
H 1916 1830 1733 1623 1564 1502 1369 1223
M 1863 1778 1681 1573 1515 1453 1321 1178
L 1611 1534 1447 1348 1294 1238 1118 986
1000DA
H
2047 1952 1850 1740 1683 1623 1498 1366
M
1995 1902 1800 1690 1631 1571 1443 1307
L
1677 1604 1520 1427 1376 1322 1207 1082
1200DA
H 2577 2522 2465 2406 2376 2345 2281 2215
M 2379 2334 2286 2235 2209 2182 2126 2066
L 1738 1723 1704 1681 1668 1655 1624 1590
1400DA
H
2637 2562 2490 2421 2387 2353 2288 2226
M
2594 2536 2475 2413 2381 2349 2284 2216
L 2059 2027 1992 1953 1932 1910 1863 1813
1600DA
H 3464 3384 3299 3210 3164 3116 3018 2916
M 3229 3162 3091 3014 2975 2934 2848 2758
L 2430 2407 2376 2336 2313 2288 2232 2168
