Performance Data
Cooling Capacity (The tables below are two examples)
NOTES:
1) THE FIRST TABLE IS UNDER MEDIUM SPEED,BUT THE SECOND TABLE IS BASED ON THE ARI STANDARD 440-2005 IN HIGH SPEED.
2) CAPACITY UNDER DIFFERENT CONDITIONS CAN BE DERIVED BY SELECTION SOFTWARE.
Model
ESP
Entering air
Temperature( )
Chilled water
Temperature( )
Cooling Capacity (kw) Water ow
Water Pressure
Drop
Pa DB WB In Out Total Sensible m
3
/h kPa
MCW200DA 75 24 18 5.5 14.5 1.65 0.98 0.16 3
MCW300DA 75 24 18 5.5 14.5 2.30 1.41 0.22 6
MCW400DA 75 24 18 5.5 14.5 3.30 2.04 0.31 13
MCW500DA 75 24 18 5.5 14.5 3.75 2.58 0.36 6
MCW600DA 75 24 18 5.5 14.5 4.30 2.86 0.41 8
MCW800DA 75 24 18 5.5 14.5 6.59 4.50 0.63 10
MCW900DA 75 24 18 5.5 14.5 7.17 4.88 0.68 13
MCW1000DA 75 24 18 5.5 14.5 7.91 5.48 0.75 11
MCW1200DA 75 24 18 5.5 14.5 9.96 6.77 0.83 11
MCW1400DA 75 24 18 5.5 14.5 10.43 7.84 0.98 15
MCW1600DA 75 24 18 5.5 14.5 13.00 9.97 1.23 20
Model
ESP
Entering air
Temperature(℃)
Water
Temperature(℃)
Cooling Capacity (kw) Water ow
Water Pressure
Drop
Pa DB WB In Out Total Sensible m
3
/h kPa
MCW200DA 50 26.7 19.4 7.2 15.6 2.33 1.47 0.24 6
MCW300DA 50 26.7 19.4 7.2 15.6 3.16 2.08 0.32 12
MCW400DA 50 26.7 19.4 7.2 15.6 4.20 2.81 0.43 23
MCW500DA 50 26.7 19.4 7.2 15.6 4.64 3.40 0.47 10
MCW600DA 50 26.7 19.4 7.2 15.6 5.38 3.83 0.55 14
MCW800DA 50 26.7 19.4 7.2 15.6 8.10 5.89 0.83 17
MCW900DA 50 26.7 19.4 7.2 15.6 8.76 6.34 0.89 20
MCW1000DA 50 26.7 19.4 7.2 15.6 9.51 7.03 0.97 16
MCW1200DA 50 26.7 19.4 7.2 15.6 10.39 8.53 1.06 17
MCW1400DA 50 26.7 19.4 7.2 15.6 11.84 9.36 1.21 22
MCW1600DA 50 26.7 19.4 7.2 15.6 15.18 12.36 1.55 30
