Components Data
NOTE:
ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL 200DA 300DA 400DA 500DA 600DA 800DA 900DA
1000DA
1200DA 1400DA 1600DA
FAN
TYPE Centrifugal (Blade: Forward-curved)
QUANTITY 1 2 2 2 2 3 4 4 3 3 4
MATERIAL Galvanized Steel
DRIVE Direct Drive
DIAMETER
mm 160 160 160 160 160 160 160
160 200
200 200
in 6.30 6.30 6.30 6.30 6.30 6.30 6.30
6.30 7.87
7.88 7.88
LENGTH
mm 200 160 200 200 200 200
160 200 190
190 190
in 7.87 6.30 7.87 7.87 7.87 7.87
6.30 7.87 7.48
7.48 7.48
MOTOR
TYPE Split-capacitor Motor With Ball Bearing
NUMBER OF MOTORS 1 2
POWER SUPPLY 220-240V/1ph/50Hz
IP/INSULATION CLASS IP20/Class B
POLES 4
COIL
TYPE Seamless Copper Tube Mechanically Bonded To Corrugated Aluminum Fin
TESTING PRESSURE Pressure Test:3.3mpa For 1 Minute; Leakage Test:1.6mpa For 5 Minutes
TUBE
MATERIAL Copper
DIAMETER
mm 9.52
in 3/8
THICKNESS
mm 0.3
in 0.012
FIN
MATERIAL Hydrophilic Aluminum
THICKNESS
mm 0.11
in 0.0043
FACE AREA
m
2
0.09 0.12 0.14 0.16 0.18 0.24 0.26 0.30 0.30 0.33 0.41
ft
2
141 185 217 242 273 377 409 472 472 511 629
ROW 4
FIN PER INCH 10
INSULATION
COIL TOP
PANEL
MATERIAL Fibre Glass
THICKNESS mm 8
OTHER
PANELS
MATERIAL PE Foam
THICKNESS mm 5 5 5 5 5 5 5 5 5 5 5
DRAIN
PAN
MATERIAL PE Foam
THICKNESS mm 7 7 7 7 7 7 7 7 7 7 7
AIR FILTER
MATERIAL Aluminium Frame Nylon Filter
NUMBER 1 1 2 2 3 3 3 3 3 3 3
SIZE
LENGTH mm 485 665 765 805 905 1235 1375 1535 1252 1337 1637
WIDTH mm 236 236 236 236 236 236 236 236 292 292 292
THICKNESS mm 8 8 8 8 8 8 8 8 8 8 8
