McQuay MicroTech 200 Series User Manual

OM 200MICRO 23
Menu 10, Auto Logging
Item
Screen Line Display Field Range Extended Name
1 Wk Ending 1 Date of Current Log
Peak=xxx% 1 Recorded Peak % RLA
2
Evap=xx.xxpsi 2 Recorded Evaporator Pressure
mm-dd xx:xx 1 Date and Time of Log Entry
1
3
Cond=xxx.xpsi 2 Recorded Condenser Pressure
Ent Evap=xx.x°F 1 Recorded Ent Evap Water Temp
1
Ent Cond=xx.x°F 2 Recorded Ent Cond Water Temp
Lvg Evap=xx.x°F 1 Recorded Lvg Evap Water Temp
2
Lvg Cond=xx.x°F 2 Recorded Lvg Cond Water Temp
Evap Aprch=xx.x°F 1 Recorded Evap Approach
2
3
Cond Aprch=xx.x°F 2 Recorded Cond Approach
Discharge=xx.x°F 1 Recorded Discharge Temp
1
SubCool=xx.x°F 2 Recorded Subcooling
Dsch Suprht=xx.x°F 1 Recorded Discharge Superheat
3
2
Suct Suprht=xx.x°F 2 Recorded Suction Superheat
1 Sump Temp=xx.x°F 1 Recorded Oil Sump Temp
Feed Temp=xx.x°F 1 Recorded Oil Feed Temp
2
Evap Flow=xx.x°F 2 Recorded Evap Water Flow
Feed Press=xx.xpsi 1 Recorded Oil Feed Pressure
4
3
Cond Flow=xxxxpgm 1 Recorded Cond Water Flow
1 Wk Ending 1 Date of Previous Log
Peak=xxx% 1 Recorded Peak % RLA
2
Evap=xx.xpsi 2 Recorded Evap Pressure
mm-dd xx:xx 1 Date and Time of Log Entry
5
3
Cond=xxx.xpsi 2 Recorded Cond Pressure
Ent Evap=xx.x°F 1 Recorded Ent Evap Water Temp
1
Ent cond=xx.x°F 2 Recorded Ent Cond Water Temp
Lvg Evap=xx.x°F 1 Recorded Lvg Evap Water Temp
2
Lvg Cond=xx.x°F 2 Recorded Lvg Cond Water Temp
Evap Aprch=xx.x°F 1 Recorded Evap Approach
6
3
Cond Apprch=xx.x°F 2 Recorded Cond Approach
Discharge=xx.x°F 1 Recorded Discharge Temp
1
Subcool=xx.x°F 2 Recorded Subcooling
Dsch Suprht=xx.x°F 1 Recorded Discharge Superheat
7
2
Suct Suprht=xx.x°F 2 Recorded Suction Superheat
1 Sump Temp=xx.x°F 1 Recorded Oil Sump Temp
Feed Temp=xx.x°F 1 Recorded Oil Feed Temp
2
Evap Flow=xxxxgpm 2 Recorded Evap Water Flow
Feed Press=xx.xpsi 1 Recorded Oil Feed Pressure
8
3
Cond Flow=xxxxgpm 2 Recorded Cond Water Flow
