McQuay WSC

58 OM Centrif Micro ΙΙ-5
Set Alarm Setpoints
SET ALARM LMTS (1)
LowEvPrHold=XXXpsi
LowEvPrUnld=XXXpsi
LowEvPrStop=XXXpsi
SET ALARM LMTS (2)
HighCondPr=XXXXpsi
HiDschT-Load=XXX°
°°
°F
HiDschT-Stop=XXX°
°°
°F
SET ALARM LMTS (3)
HiOilFeedTmp=XXX°
°°
°F
LowOilDeltaT =XX°
°°
°F
LowNetOilPr=XXXpsi
SET ALARM LMTS (4)
HighSSH-Start=XX°
°°
°F
HighSSH-Run =XX°
°°
°F
MtrCurrThrshld=XX%
SET ALARM LMTS (5)
Evap Freeze=XX.X°
°°
°F
Cond Freeze=XX.X°
°°
°F
Set Tower Setpoints
NOTE: A complete description of the setup for cooling towers is found on page 31.
SET TOWER SPs (1)
TowerControl = None
Tower Stages = x
StageUP/DN=XXX/XXX%
TowerControl settings can be None, Temp, or Lift. Stages is the number of fans controlled, 1 to 4.
Tower Control = Temp/None Tower Control = Lift
SET TOWER SPs (2) SET TOWER SPs (2)
Stage ON (Temp)°
°°
°F
Stage ON (Lift)psi
#1 #2 #3 #4 #1 #2 #3 #4
XXX XXX XXX XXX XXX XXX XXX XXX
Tow e r C on trol=Temp/ No ne Tow er Con tro l= Lift (p si)
SET TOWER SPs (3)
SET TOWER SPs (3)
StageDiff = XX.X°
°°
°
F
StageDiff =XX.Xpsi
Stage Up = XX min
Stage Up = XX min
StageDown = XX min
StageDown = XX min
