DUCTING INSTRUCTIONS - INDICATIONS POUR LA CANALISATION
A
B
C
D
B
A
B
C
D
E
A > 4 ft
B ≥ 4 ft
C As short as possible - Le plus court possible
D > 5°
E Windproof terminal - Terminal anti-vent
