MCS BV 170E - Page 92

UNIT 3
PARTS LIST
POS. Code NR Description
Rev. - - Mar. 2015
1
4032.546
UPPER BODY
2
4032.548
UPPER BODY MOBILE
3
4032.385
CHIMNEY
4
4032.557
INLET GRILLE
5
4033.378
MOTOR
6
4033.030
FAN
7
4032.554
AIR FLAP
8
4104.170
CLIP NUT
9
4111.056
PROTECTION CLABLE
10
4032.555
MOTOR FLANGE
12
4160.646
PROTECTION CLABLE
13
4111.241
ELASTIC PLATE
14
4032.568
HANDLE FRAME
15
4165.545
TANK CAP
16
4290.083
TANK FILTER
17
4100.632
DRAIN PLUG
18
4032.564
FOOT FRAME
19
4111.057
PLUG
20
4032.536
POWER CORD HOOK
21
4032.094
WHEEL Ø 250
22
4111.480
WHEEL PLUG
23
4111.072
WHEEL HOLDER Ø 20
24
4032.566
AXLE
25
4033.242
FUEL TANK
26
4032.558
ELECTR. COMPONENTS DRAWER PANEL
27
4033.095
BASE
28
4032.560
SIDE PANEL
29
4032.380
LOWER BODY
30
4033.188
COMBUSTION CHAMBER
31
4031.659
OUTLET CONE
32
4031.068
CONN. STRAIGHT 1/4"
33
4031.067
PIPE CONNECTION 1/4"
34
4031.062
FUEL PIPE PUMP-TANK
35
4031.063
FUEL PIPE TANK-FILTER
36
4031.061
FUEL PIPE FILTER-PUMP
37
4033.090
FILTER CARTIDGE 3/8"
38
4111.116
OR KIT FILTER
39
4031.494
FILTER CARTIDGE
40
4032.437
FILTER SUPPORT
41
4031.064
DOUBLE SCREW
43
4160.646
PROTECTION CABLE
44
4033.257
PLASTIC BOX
45
4033.343
HT CABLE
46
4033.344
POWER CORD TRANSFORMER HT
47
4111.897
TRANSFORMER HT
48
4033.360
CONTROL BASE
49
4033.318
CONTROL BOX
50
4160.639
POP RIVET 4 WAY
51
4031.514
RELAY
52
4033.529
FUSE
53
4033.528
FUSE HOLDER
54
4033.248
FRONTAL CONTROLS PANEL
55
4106.034
PANEL LABEL
56
4100.656
LOCKNUT
57
4150.528
STRAIN RELIEF BUSHING
ESP00352
MODEL BV 170E - 120 V / 60 Hz
