MCS BV 170E - Page 96

UNIT 3 PARTS LIST
POS. Code NR Description
Rev. - - July 2014
1
4111.604
UPPER BODY
2
4033.263
UPPER BODY MOBILE
3
4111.241
ELASTIC PLATE Ø 4,2
4
4032.465
INLET GRILL
5
4032.498
MOTOR
6
4032.716
MOTOR FLANGE SUPPORT
7
4033.019
FAN
8
4111.056
PROTECTION CABLE
9
4032.518
CENTRAL AIR FLAP
10
4104.170
CLIP NUT
11
4033.223
OUTLET CONE
12
4033.197
COMBUSTION CHAMBER
13
4033.264
LOWER BODY
14
4111.610
AIR FLAP
15
4032.470
BASE
16
4032.466
ELECTR. COMPONENTS DRAWER PANEL
17
4032.468
SIDE PANEL
18
4032.536
POWER CORD HOOK
19
4160.646
PROTECTION CABLE
20
4260.100
TANK CAP
21
4290.083
TANK FILTER
22
4032.480
HANDLE FRAME
23
4032.476
FOOT FRAME
24
4100.632
DRAIG PLUG
25
4033.243
FUEL TANK
26
4111.480
WHEEL PLUG
27
4111.072
WHEEL PLUG Ø 20
28
4110.978
WHEEL
29
4032.478
AXLE
30
4101.151
PROTECTION CABLE
32
4031.068
CONN. STRAIGHT 1/4"
33
4031.062
FUEL PIPE PUMP-TANK
34
4031.067
PIPE CONNECTION 1/4"
35
4031.063
FUEL PIPE TANK-FILTER
36
4033.090
FILTER SUPPORT
37
4031.494
FILTER WITH CARTIDGE 3/8"
38
4031.064
FILTER CARTIDGE
39
4031.061
DOUBLE SCREW
40
4033.373
FUEL PIPE FILTER-PUMP
41
4111.116
OR KIT FILTER
43
4160.646
PROTECTION CABLE
44
4033.257
PLASTIC BOX
45
4033.343
HT CABLE
46
4033.344
POWER CORD TRANSFORMATOR HT
47
4111.897
TRANSFORMER HT
48
4033.249
CONTROL BASE
49
4033.318
CONTROL BOX
50
4160.639
POP RIVET 4 WAY
51
4031.514
RELAY
52
4033.529
FUSE
53
4033.528
FUSE HOLDER
54
4033.248
FRONTAL CONTROLS PANEL
55
4033.254
PANEL LABEL
56
4100.656
LOCKNUT
ESP00325
MODEL B360 - 120 V / 60 Hz
