ATMe, Haze Generator
User Guide, Rev: C/e, March 2023 13 / 33
DMX,RDM DMX / RDM Menu
DMX ADDR yyy DMX Address (1 to 510)
DEV LABEL yyyyyy RDM Device Name
DEV ID yyyyyy RDM Device ID
1 UNIT yyy Channel #1 value: OFF
≤
50% (128)
<
ON
2 OUTPUT yyy Channel #2 value: 0% (0) to 100% (255)
3 HAZE yyy Channel #3 value: OFF
≤
50% (128)
<
ON
TIMER Timer Menu
ENABLED ---- Timer toggle
OFF - the timer is disabled (Pause)
ON - the timer is enabled (Running)
SET PRES xx.x Timer HAZE operating pressure (see Units)
CCL.CLOCK HH:MM:SS Cycle Clock
ON (MIN) yyy ON Time Delay for each Cycle (1 to 60 min)
OFF (MIN) yyy OFF Time Delay for each Cycle (1 to 120 min)
END (MIN) yyy Shutdown Time (0 to 720 min) | 0 = No Shutdown
SETTINGS Settings menu
UNITS ---- Units toggle
PSI/°C - pressure in psi, temperature in Celsius
kPA/°C - pressure in kPa, temperature in Celsius
BAR/°C - pressure in bar, temperature in Celsius
PSI/°F - pressure in psi, temperature in Fahrenheit
LCD SAVER ---- LCD Saver Mode
30 s - LCD saver is activated after 30 s
2 mn - LCD saver is activated after 2 min
OFF - LCD Saver is Off
VOLTAGE xxxx For diagnostic issue
VERSION x.xx Model Version
FIRMWARE x.xx Program Firmware
