Amplifier Fuse Total
0,1 - 1m 1 - 2m 2 - 3m 3 - 4m 4 - 4,5m 4,5 - 5,1m 5,1 - 6m
In Amperes
MDS T10 XTR 300A +
70mm² 70mm² 70mm² 70mm² 2 x 50mm² 2 x 50mm² 2 x 70mm²
MDS T9 XTR 250A - 300A
Lenght of Wire
Power Cable Selecion Chart (copper)
*** WARNING ***
Upside down mounting will compromise heat dissipation through the heat
sink and could engage the thermal protection circuit.
Try to avoid mounting the amplifier on a subwoofer enclosure, as extended
exposure to vibration may cause malfunction of the amplifier.
Don’t mount the amplifier so that the wire connections are unprotected or
are subject to pinching or damage from nearby objects.
The DC power wire must be fused at the battery positive (+) terminal con-
nection. Before making or breaking power connections at the amplifier pow
er terminals, disconnect the DC power wire at the battery end.
The battery of the car audio system must be disconnected until the entire
wiring and installation is completed.
Don’t use a power drill to tighten the power, ground, remote or speaker out
put terminals on the amplifier to avoid stripping the terminal screws. It is
best to hand tighten these connections.
The use of Ring and Spade terminals (not included) provides the best electri
cal connection for use with the clamp style connections on this amplifier.
Don’t mount the amplifier directly on the enclosure! Vibrations from the en
closure can damage the amplifier!
18
