5. GAIN Control
This control is used to match the input sensitivity of the amplifier to the particular source
6. SUB SONIC Control
provide an extra level of subwoofer protection from bass robbing power at unheard fre-
quencies.
7. LPF (Low Pass Filter) Control
eliminate unwanted high frequencies.
8. SPEAKER Output Terminals
As shown in the wiring diagrams, be sure to observe speaker polarity through the system
and speaker impedance. The clamp style wire terminal is designed to accommodate up
9. POWER/STATUS Indicator
10. FUSES
For convenience most MDS amplifiers utilize common automotive ATC type fuses. For
continued protection in the event that a fuse blows, replace the fuse only with the same
value.
These power fuses on the amplifier chassis are for protecting the amp against
over current situation. To protect the vehicles electrical system, an additional fuse should
11. BATT+ (Power Input Connection)
This terminal is the main power input for the amplifier and must be connected directly to
-
mended wire “mm” for each model.
12. REM (Remote Input Connection)
on the rear of the source unit in the form of an electric antenna output, or a remote out-
wire is sufficient to run the REMOTE.
13. GND (Ground Input Connection)
A good quality ground is required for your MDS amplifier to operate at peak perfor-
mance. A short length of cable the same “mm” as your power cable should be used to
attach the ground terminal directly to the chassis of the vehicle. Make sure that all of the
paint is sanded or scraped away to ensure a quality ground connection.
