Remove The Dust Covers:
The dust covers located at the front and rear of the telesocpe protect the telescope
STEP 1: Remove dust covers(6) at the front of the scope by pulling the cover away from the telescope. Set aside
so you can re-install it after use.
STEP 2: Remove the dustcover from the focuser by pulling it out of the focuser drawtube. Set aside so you can
re-install it after use.
Insert The Erect-Image Prism (EclipseView60 Models Only):
The 90° Erect-Image Prism reflects the light from the optical tube to a more comfortable viewing position. It also
reorients (corrects) the image so the object appears right side up and left-right correct. This makes the EclipseView60
and ideal choice for both terrestrial viewing and night time observing.
STEP 1: To install, slide the diagonal prism into the focuser draw tube.
STEP 2: Tighten the draw tube thumbscrew to hold the diagonal prism securely.
