EclipseView 76
Always use the EclipseView Solar Filter when viewing at or near the Sun or irreversible eye damage may occur.
1. Tripod leg lock
2. Leg brace supports
3. Accessory tray
4. Alt-Az mount
5. Azimuth motion lock knob
6. Altitude lock knobs
7. Optical tube assembly
(OTA)
8. Primary Mirror
9. Solar Filter
*Required for viewing the
Sun.
10. SunFinder
11. Finder mounting knobs
12. Red-dot finder
13. Red-dot finder On/Off
switch
14. Red-dot finder adjust-
ments
15. Eyepiece
16. Focuser
17. Focus knobs
18. Focuser thumbscrews
19. Slow-motion control rod
20. Slow-motion lock knob
21. OTA mounting knobs(2)
22. Front dust cap (not visible)
23. Primary mirror adjustment
screws
24. Secondary mirror adjust-
ment screws
1
1
2
3
5
12
7
9
10
14
13
Image A
Image B
Image C
FIGURE 1B
Image D
10
9
Telescope Features
4
8
11
15
16
17
22
23
24
7
18
21
12
19
20
6
To Next Page
