DC30D GENSET CONTROLLER USER MANUAL
25
19.Oil pressure sensor 3015237
20.Oil pressure sensor WEICHAI 0-0.6MPa
21.Oil pressure sensor GENCON 0-10Bar
22.Self-define oil pressure sensor
7
Programmabl
e input 4
（Functional
of PIN 9）
0-24
(11.Temperature
sensor VDO 40-
120 ℃ )
0.Disable.
1.Remote start (on load).
2.Low oil pressure alarm switch input.
3.High temperature alarm switch input.
4.Low water level alarm switch input.
5.Low fuel level warning switch input.
6.Low fuel level alarm switch input.
7.External instant warning input.
8.External instant alarm input.
9.High temperature shutdown disabled: When the
signal is valid and the generator is in normal
operation, if there is a high temperature alarm, the
controller will stop the generator after high-speed heat
dissipation delay; when the signal is invalid, if there is
a high temperature alarm, the controller will stop
directly.
10.Reserve for switching input
11.Temperature sensor VDO 40-120 ℃
12.Temperature sensor MEBAY-001B
13.Temperature sensor SGH
14.Temperature sensor SGD
15.Temperature sensor SGX
16.Temperature sensor CURTIS
17.Temperature sensor DATCON
18.Temperature sensor VOLVO-EC
19.Temperature sensor 3015238
20.Temperature sensor PT100
21.Temperature sensor MEBAY-Mier
22.Temperature sensor WEICHAI 40-120℃
23.Temperature sensor GENCON 40-120℃
24.Self-define temperature sensor
6)LCD setting
No
Parameter
Range(defaults)
Notes
1
Start screen
display
0-20.0s(5.0s)
Start screen display time,0: No-display.
2
Saving mode
5.0-6000.0s
(600.0s)
LCD light will be closed automatically without any
button pressed after delay.If setting as 200.0s,
back light always lighted.
3
Homing display
5.0-600.0s
(600.0s)
The time when the page reverts back to the home
page .If setting as 600.0s:disabled.
4
LOGO delay
5.0-6000.0
Start screen will be opened without any button
