DC32D GENSET CONTROLLER USER MANUAL
22
7-Românesc
8-Polski
9-Português
10-Deutsch
11-한국어
12-Tiếng Việt
13- ةيبرعلاب
14-Bahasa Indonesia
15-یسراف;
1
Gens poles
2/4/6/8(4)
When the flywheel teeth is set as 0,the RPM
will be resulted by frequency.
Pole 2: 50Hz---3000RPM.
Pole 4: 50Hz---1500RPM.
Pole 6: 50Hz---1000RPM.
Pole 8: 50Hz---750RPM
2
Gens enable
Disable
Enable
Gens enable:
No Gens parameters can be displayed if
setting as disable, which is applied to water
pump Genset.
3
Rated frequency
40.0-80.0Hz(50.0Hz)
Calculate the alarm value.
4
Rated voltage
80-600V(230V)
Calculate the alarm value.
5
Rated battery
voltage
8.0-36.0V(12.0V)
Calculate the alarm value. One battery gens
should be set as 12V, two batteries gens
should be set as 24V.
6
Rated RPM
500-4500RPM(1500)
Calculate the alarm value.
7
Flywheel teeth
0-300(0)
If the setting is 0, (RPM sensor Disabled), then
RPM is resulted by Hz.
8
Temperature unit
℃
F
Unit display.
9
Power on Mode
STOP
Auto
Auto save
The mode of Controller after Power-on.
Note: Auto save function can not record the
mode with manual.
10
Manual crank
times
1-30 (1 time)
Crank times under mode and test mode.
11
Auto start crank
times
1-30 (3 times)
Crank times under auto mode.
12
E.T.S. hold times
1-10(2 times)
The max E.T.S. hold on power shall be
canceled once stop success under auto mode .
the output interval time is " Fail to stop ".
13
Crank
disconnect
RPM
Frequency
RPM/Frequency
1.Please check if the running status, stop
condition are according with crank condition.
2.Means either of the conditions can be
acceptable as crank condition. But all of them
should be meet together to regard as stop
condition.
14
Frequency
disconnect
0-200%(28%)
Rated frequency multiplying by this value is
regarded as crank success condition. When
the gens frequency is over the condition value,
then system regards it as crank success.
15
RPM disconnect
0-200%(24%)
Rated RPM multiplying by this value is
