DC32D GENSET CONTROLLER USER MANUAL
27
SWITCH 2
（Functional
of PIN 7）
(2. Low oil
pressure alarm)
1.Remote start switch input.
2.Low oil pressure alarm switch input.
3.High temperature alarm switch input.
4.Low water level alarm switch input.
5.Low fuel level warning switch input.
6.Low fuel level alarm switch input.
7.External instant warning input.
8.External instant alarm input.
9.High temperature cooling and Stop Input : When
the signal is valid and the generator is in normal
operation, if there is a high temperature alarm, the
controller first after the Cooling time delay after the
temperature is lower than the high temperature alarm
value before stopping; when the signal is invalid, if
there is a high temperature alarm, the controller will
stop directly.
10.Emergency stop.
11.Pump fail alarm switch input-Normally
closed valid.
12.Pump fail warning switch input-Normally
closed valid.
13.Pump fail alarm switch input-Normally open valid.
14.Pump fail warning switch input-Normally
open valid.
4
AUX. INPUT 1
（Functional
of PIN 8）
0-24
(12.Temperature
sensor VDO 40-
120 ℃ )
0.Disable.
1.Remote start (on load).
2.Low oil pressure alarm switch input.
3.High temperature alarm switch input.
4.Low water level alarm switch input.
5.Low fuel level warning switch input.
6.Low fuel level alarm switch input.
7.External instant warning input.
8.External instant alarm input.
9.High temperature shutdown disabled: When the
signal is valid and the generator is in normal
operation, if there is a high temperature alarm, the
controller will stop the generator after high-speed
heat dissipation delay; when the signal is invalid, if
there is a high temperature alarm, the controller will
stop directly.
10.Reserve for switching input
11.Self-define temperature sensor
12.Temperature sensor VDO 40-120 ℃
13.Temperature sensor MEBAY-001B
14.Temperature sensor SGH
15.Temperature sensor SGD
16.Temperature sensor SGX
17.Temperature sensor CURTIS
18.Temperature sensor DATCON
19.Temperature sensor VOLVO-EC
