DC32D GENSET CONTROLLER USER MANUAL
28
20.Temperature sensor 3015238
21.Temperature sensor PT100
22.Temperature sensor MEBAY-Mier
23.Temperature sensor WEICHAI 40-120℃
24.Temperature sensor GENCON 40-120℃
5
AUX. INPUT 2
（Functional
of PIN 9）
0-31
(0.Disable)
0.Disable.
1.Remote start switch input.
2.Low oil pressure alarm switch input.
3.High temperature alarm switch input.
4.Low water level alarm switch input.
5.Low fuel level warning switch input.
6.Low fuel level alarm switch input.
7.External instant warning input.
8.External instant alarm input.
9.High Temperature cooling and Stop Input : When
the signal is valid and the generator is in normal
operation, if there is a high temperature alarm, the
controller will stop the generator after high-speed
heat dissipation delay; when the signal is invalid, if
there is a high temperature alarm, the controller will
stop directly.
10.Reserve for switching input
11.Self-define fuel level sensor
12.Fuel level sensor 0-100Ω
13.Fuel level sensor 100-0Ω
14.Fuel level sensor 0-107Ω
15.Fuel level sensor 107-0Ω
16.Fuel level sensor 0-180Ω
17.Fuel level sensor 180-0Ω
18.Fuel level sensor 180-10Ω
19.Fuel level sensor 10-180Ω
20.Fuel level sensor 120-10Ω
21.Fuel level sensor 10-120Ω
22.Fuel level sensor 90-0Ω
23.Fuel level sensor 0-90Ω
24.Fuel level sensor 0-30Ω
25.Fuel level sensor 73-10Ω
26.Fuel level sensor 240-33Ω
27.Fuel level sensor 33-100Ω
28.Fuel level sensor 0-200Ω
29.Fuel level sensor 200-0Ω
30.Fuel level sensor 0-190Ω
31.Fuel level sensor 190-0Ω
6)Mains protection
No
Parameter
Range(defaults)
Notes
1
Phase
Disable
1 Phase 2 Wire
2 Phase 3 Wire
Choose the input, there is no display if setting
as disable.
