Mec 1330SE - TroubleshootNg Table

Page 30 1330SE - Service & Parts Manual
November 2019Section 10 - Control System
Troubleshooting Table
Error Code Troubleshooting
10
System Initialization Fault: ECU may be malfunctioning.
System Communication Fault: Check communications cable connections and other wiring.
Contact MEC Customer Service
20 System Initialization Fault: TM1 may be malfunctioning. Contact MEC Customer Service.
30
System Initialization Fault: PCU may be malfunctioning.
System Communication Fault: Check communications cable connections and other wiring.
Contact MEC Customer Service.
31 Contact MEC Customer Service.
32 Contact MEC Customer Service.
51
System Initialization Fault: ECU may be malfunctioning.
System Communication Fault: Check communications cable connections and other wiring.
Contact MEC Customer Service.
52
System Initialization Fault: PCU may be malfunctioning.
System Communication Fault: Check communications cable connections and other wiring.
Contact MEC Customer Service.
53 System Initialization Fault: TM1 may be malfunctioning. Contact MEC Customer Service.
54
Pressure Sensor Fault: Check the wiring to the sensor and then the sensor itself. Also check to make sure that
the correct option is properly selected (or not) for load sensing
55
Angle Sensor Fault: Check the wiring to the sensor and then the sensor itself. Also check to make sure that
the correct option is properly selected (or not) for load sensing
56
Level Sensor Fault: Check the wiring to the sensor and then the sensor itself. Also check to make sure that the
correct option is properly selected (or not) for load sensing
57 Overloaded Platform Fault: Remove the excess load immediately
58
Pothole Guard Fault: Check that the pothole guards are extended, check the pothole limit switches. Check
wires to the switches, check the down limit switch and connections
59 The platform has reached the highest position
60 The platform has reached the 2.5 m position
61 Machine Tilted Beyond Safe Limits Fault: If the machine is tilted, find a way to make it level.
62 Machine Tilted Beyond Safe Limits Fault: If the machine is tilted, find a way to make it level.
63 The platform has reached the Anti-hand pinch position
64
Left Brake Coil Fault: Check the connections to the Coil’s terminals and make sure they are tight. If so, check
the coil itself to see if it is open or shorted.
65
Right Brake Coil Fault: Check the connections to the Coil’s terminals and make sure they are tight. If so, check
the coil itself to see if it is open or shorted.
66 Charge battery
69 Restart the power
90 TM1 over current
91 TM1 over current
95 Turning the traction motor
99 Bypass was enabled by human
101-115 Contact MEC Customer Service or replace ECU
201-231 Contact MEC Customer Service or replace TM1
