Mec 1330SE - Page 53

Page 49 1330SE - Service & Parts Manual
November 2019Section 12 - Chassis
Item Part Number Description Qty.
1 53056 HHMS M05-0.80 × 12 10
2 53043 WSHR M05 Spring Washer 14
3 53038 WSHR M05 Standard Flat 17
4 41308 Cover Plate 1
5 41309 Cover 1
6 41310 Beacon 1
7 50591 BHCS M05-0.80 × 20 2
8 41311 Cover Plate 1
9 50524 NNYL M05-0.80 2
10 41312 Cover, Sensor 1
11 41306 Plate, Rear Cover 1
12 50031 HHCS M08-1.25 × 25 4
13 53055 WSHR M08 Spring Washer 4
14 50001 WSHR M08 Standard Flat 4
15 41193 Ladder Weldment 1
16 53026 BHCS M06-1.00 × 12 13
17 53046 WSHR M06 Spring Washer 5
18 50000 WSHR M06 Standard Flat 5
19 41194 Support Plate, Sensor 1
20 41195 Rotary Sensor 1
21 53065 SHCS M04-0.70 × 30 2
22 41575 Input Socket 1
23 50423 SHCS M04-0.70 × 12 10
24 50034 HHCS M10-1.50 × 30 8
25 50273 Nordlock 7/16 8
26 50002 WSHR M10 Standard Flat 8
27 41313 Drive Wheel Assembly (Refer to Page 54) 2
28 41196 Lock Plate 2
29 53044 SHMS M05-0.80 × 10 4
30 41219 Mid Linkage Weldment 1
31 41314 Battery Pack Module 1
32 53066 SHCS M10-1.50 × 15 2
33 41197 Switch, Limit 2
34 53065
SHCS M04-0.70 × 30 4
35 41315 Switch Cover 1
36 41199 Thrust Washer 2
37 41202 Bearing 4
38 41316 Steer Linkage 1
39 41198 Cover, Switch 1
40 41317 Chassis Weldment 1
41 41318 Cover 2
