Page 59 1330SE - Service & Parts Manual
November 2019Section 12 - Chassis
Item Part Number Description Qty.
1 REF Hydraulic Power Unit (Refer to Page 60) 1
2 50127 SHCS M10-1.50 × 30 2
3 53054 WSHR M10 Spring Washer 2
4 50002 WSHR M10 Standard Flat 2
5 41928 ECU Module 1
6 41329 Sleeve Pipe 1
7 53067 SHCS M05-0.80 × 40 2
8 41330 Battery 2
9 41331 DC Contactor 1
10 53068 CSCS M05-0.80 × 8 3
11 53043 WSHR M05 Spring Washer 15
12 53038 WSHR M05 Standard Flat 23
13 41332 Towline 1
14 53138 SHCS M06-1.00 × 16 4
15 41333 Fix Panel 1
16 50591 BHCS M05-0.80 × 20 4
17 41250 Traction Module 1
18 53035 BHCS M05-0.80 × 16 4
19 41334 Relay 1
20 41251 Fuse 1
21 53045 HHMS M05-0.80 × 14 2
22 50000 WSHR M06 Standard Flat 8
23 50047 NNYL M06 × 1.00 8
24 41335 Lock Latch 2
25 50028 HHCS M06-1.00 × 20 8
26 41252 Emergency Down Cable 1
27 53044 SHMS M05-0.80 × 10 6
28 41575 Input Socket 1
29 50423 SHCS M04-0.70 × 12 2
30 41934 Battery Box Weldment 1
31 41065 Power Switch 1
32 41254 Charger 2
33 50591 BHCS M05-0.80 × 20 8
34 41255
Glide Track 2
35 50524 NNYL M05-0.80 8
36 50034 HHCS M10-1.50 × 30 2
37 41337 Fix Panel 1
REF - Reference
