Page 67 1330SE - Service & Parts Manual
November 2019Section 13 - Scissor
Item Part Number Description Qty.
1 41259 Scissor Assembly 1
2 41287 Bearing, Lift Cylinder 4
3 41338 Top Slider Axle 2
4 41256 Bottom Slider 2
5 41339 Chassis Assembly 1
6 41257 Bearing 2
7 41258 Fastness Base Axle 1
8 50327 HHCS M06-1.00 × 35 4
9 50000 WSHR M06 Standard Flat 8
10 50047 NNYL M06 × 1.00 4
