Page 73 1330SE - Service & Parts Manual
November 2019Section 14 - Platform
Item Part Number Description Qty.
1 41578 Platform Guard Rail 1
2 41127 Hinge A 1
3 41579 Platform Guard Rail 1
4 41271 Connector Kit 1
5 53063 HHMS M04-0.70 × 8 1
6 41134 Clip 1
7 50047 NNYL M06 × 1.00 11
8 50000 WSHR M06 Standard Flat 15
9 50135 HHCS M06-1.25 × 50 10
10 41273 Waterproof Joint 1
11 41267 Circlip 2
12 41131 Bearing 2
13 41269 Roller 2
14 41360 Roller Installation 2
15 50290 HHCS M08-1.25 × 40 8
16 41272 Platform Deck Assembly 1
17 41275 Shield Sleeve 1
18 41128 Hinge B 1
19 53051 HHMS M06-1.00 × 16 12
20 50000 WSHR M06 Standard Flat 12
21 50294 HHCS M06-1.00 × 45 1
22 41277 Spring 1
23 41278 Latch 1
24 41574 Entry Gate 1
25 41581 Door Support Bracket 1
26 50447 HHCS M08-1.25 × 18 1
27 50001 WSHR M08 Standard Flat 1
28 50048 NNYL M08 × 1.25 1
29 91598 Cover, Outlet Box Weatherproof 1
30 92007 Outlet, 15A 120V GFCI 1
31 91597 Outlet Box, 1/2” Weatherproof 1
-- 53040 HHSM M08-15 × 0.50 4
32 92008 Strain Relief 0.50” 1
To Next Page
