Page 75 1330SE - Service & Parts Manual
November 2019Section 14 - Platform
Item Part Number Description Qty.
1 41279 Platform Guardrail 1
2 41283 Platform Guardrail 1
3 41890 Upper Control Box 1
4 41282 Mounting BKT/Platform Control Box 1
5 50258 HHCS M08-1.25 × 10 4
6 53035 BHCS M05-0.80 × 16 2
7 41120 Rubber Gasket 2
8 50524 NNYL M05-0.80 12
9 50001 WSHR M08 Standard Flat 12
10 50018 HHCS M08-1.25 × 80 12
11 41280 Platform Guardrail 1
12 50016 HHCS M08-1.25 × 55 8
13 41361 Platform Extension 1
14 50030 HHCS M08-1.25 × 20 2
15 53055 WSHR M08 Spring Washer 2
16 41140 Locking Device 1
17 41284 Slippage Of Crutch 2
18 53045 HHMS M05-0.80 × 14 8
19 53069 CSCS M06-1.00 × 20 8
20 41360 Roller Installation 2
21 41141 Roller 2
22 41131 Bearing 2
23 41267 Circlip 2
24 8909 Enclosure Service Manual 1
-- 50191 THMS M10-32 × 0.50 4
-- 50238 NNYL M10-32 4
