Page 83 1330SE - Service & Parts Manual
November 2019Section 15 - Hydraulics
Item Part Number Description Qty.
1 41362 Muffle 1
2 41287 Bearing, Lift Cylinder 4
3 -- -- --
4 41289 Valve Manifold 1
5 41746 Down Valve Cartridge 1
6 41929 Coil 1
7 41290 Lift Cylinder 1
8 50048 NNYL M08 × 1.25 2
9 53055 WSHR M08 Spring Washer 1
10 50001 WSHR M08 Standard Flat 2
11 41291 Support (E-Down Cable) 1
12 41292 Support (E-Down Bracket) 1
13 53044 SHMS M05-0.80 × 10 1
14 41293 Jib Boom 1
15 41294 Cable End Retainer 1
16 53063 HHMS M04-0.70 × 8 1
17 41295 Seal Kit Lift Cylinder 1
18 41252 Emergency Down Cable 1
