Mec 1330SE - Page 91

Page 87 1330SE - Service & Parts Manual
November 2019Section 15 - Hydraulics
Item Part Number Description Qty.
1 41911 ECU Harness 1
2 41924 Pothole Harness 1
3 41923 Rotary Sensor Harness 1
4 41922 Platform Control Box Harness 1
5 43814 Lowering Valve 1
6 41912 Beacon Harness 1
7 41913 Drive Motor Harness 2
8 41914 Pump Motor Negative Harness 1
9 41915 Pump Motor Positive Harness 1
10 41921 Battery Negative Harness 1
11 41920 Battery Harness 1
12 41919 Battery Positive Harness 1
13 41918 Fuse Harness 1
14 41917 DC Contactor Harness 1
15 41916 Motor Controller Harness 1
16 REF Ground Control Assembly (Refer To Page 64) 1
17 REF Limit Switch, Pothole (Refer To Page 48) 2
18 REF Rotary Sensor (Refer To Page 48) 1
19 REF Platform Control Box Assembly (Refer To Page 78) 1
20 REF Hydraulic Power Unit (Refer To Page 60) 1
21 REF Coil (Refer To Page 80) 1
22 REF Beacon (Refer To Page 48) 1
23 REF Relay (Refer To Page 56 or 58) 1
24 REF Left Motor (Refer To Page 54) 1
25 REF Right Motor (Refer To Page 54) 1
26 REF Motor Controller (Refer To Page 56 or 58) 1
27 REF Motor (Refer To Page 60) 1
28 REF DC Contactor (Refer To Page 56 or 58) 1
29 REF 150A Fuse Assembly (Refer To Page 56 or 58) 1
30 REF Power Switch (Refer To Page 56 or 58) 1
31 REF Battery (Refer To Page 56 or 58) 2
32 REF Charger (Refer To Page 56 or 58) 1
