Mec Crossover Series User Manual

—Specifications—
Crossover Series
2659ERT 3259ERT
Working Height* 32 ft 9.92 m 38 ft 11.75m
Platform Height 26 ft 7.92 m 32 ft 9.75 m
Maximum Drive Height 26 ft 7.92 m 32 ft 9.75 m
Stowed Height Top Guardrail 90 in. 2.29 m 96 in. 2.44 m
Rails Folded 75 in. 1.90 m 82 in. 2.09 m
Platform Floor 45 in. 1.15 m 51 in. 1.30 m
Guardrail Height 43.5 in. 1.10 m 43.5 in. 1.10 m
Toeboard Height 6 in. 15 cm 6 in. 15 cm
Machine Weight** (Unloaded) 6065 lb 2750 kg 7360 lb 3338 kg
Lift Capacity Total 1000 lb 450 kg 750 lb 340 kg
Platform 750 lb 340 kg 500 lb 225 kg
Sheet Material Rack 250 lb 113 kg 250 lb 113 kg
Deck Extension Capacity 1 Person / 250lb (113 kg) 1 Person / 250lb (113 kg)
Maximum Occupants 3 2
Length-Stowed (Overall) 103 in. 2.62 m 103 in. 2.62 m
Length-Stowed (Without Step) 105 in. 2.67 m 105 in. 2.67 m
Platform Length (Extended) 133.5 in. 3.39 m 133.5 in. 3.39 m
Platform Length (Retracted) 91 in. 2.31 m 91 in. 2.31 m
Width (Overall) 59 in. 1.5 m 59 in. 1.5 m
Platform Width (Outside) 46 in. 1.17 cm 46 in. 1.17 cm
Sheet Rack Width 8 in. 20 cm 8 in. 20 cm
Wheel Base 82 in 2.1 m 82 in 2.1 m
Turning Radius--Inside 59 in. 1.5 m 59 in. 1.5 m
Ground Clearance 6 in 15 cm 6 in 15 cm
Drive Speed (Proportional) Stowed 0-3.2 mph 0-5 km/h 0-3.0 mph 0-4.8 km/h
Raised or extended 0-.5 mph 0-8 km/h 0-.5 mph 0-8 km/h
Gradability 35%/19° 31%/17°
Breakover Angle 30%/16.7°
Ground Pressure/Wheel 93 psi
6.5 kg/cm
2
104 psi
7.3 kg/cm
2
Maximum Wheel Load 2120 lb 960 kg 2430 lb 1100 kg
Maximum Operating Wind Speed 28 mph / 12.5 m/sec (45 km/h)
Tire Size 23" x 10" / .58m x .25m
Tire Pressure 55 psi
Lug Nut Torque 130 ft/lb 176 Nm
Hydraulic Pressure Drive System 3200 psi/ 220 bar
Lift System 2400 psi / 165 bar
Steer System 1500 psi / 103 bar
Hydraulic Fluid Capacity 14 gal / 64 liter
Power System Volt age 48 Volt D C†
Battery Charger Input 100-240 V AC, 50-60 Hz, 12 Amp
Output 48 Volt DC, 20 Amp, Automatic Shut-off†
Batteries Eight 6-Volt deep cycle; 250 Ah @ 20 hour rating†
Motor 8 HP (6kW), 3600RPM 48V Motor†
Meets applicable requirements of ANSI A92.6-2006.
*Working Height adds 6 feet (2 m) to platform height. **Weight may increase with certain options.
†Machines prior to serial numbers 13000032 (2659ERT) and 13100028 (3259ERT) use 36V systems. Contact MEC
Customer Service for information.
