Page 24 92555
June 1, 2012 Crossover Series
Crossover Series Operating Instructions & Function Tests
Fold Down Platform Railings
ART_3838
Spring Pin
10 places
1
Remove the spring pins as needed
to perform the following steps.
Fold down the
Extension Deck side rails.
Fold down the
Extension Deck front rail.
Fold down the
Personnel Entry rail.
Fold down the
Main Deck side rails.
2
3
4
5
To return the machine to normal operation mode:
• Lift all rails into their upright position, then secure them with spring pins
• Check that the Personnel Entry closure functions properly
• Position the platform control box on the front right rail of the machine.
DO NOT use the machine until all closures and guard rails are in position and properly secured.
