SR-MECAIR | 1 INTRODUCTION
1.4 Parts supplied
1. External unit
2. Internal unit: air diffuser
3. Remote control with two batte-
ries AAA batteries supplied
4. User manual
5. Power cable
6. Sealing and fixing frame
7. Roof spacers
8. Perimeter seal
9. Air seal
10. Nut cover
11. M6x60 threaded grub screws
12. Rubber washer
13. Spacer for tightening screws
1
2
4 5 6
97
3
55 mm
60 mm
65 mm
8
10 11 12 13
