mecair SR C17 - Power Cable Connection Preparation

75
EN
3.5 Preparation of the power cable connection
Provide a feed-through hole for the power cable at the attachment point,
e.g. in the false ceiling.
WARNING! Before moving the device horizontally on the roof and
inserting it into the opening, make sure that the expanded perimeter seal
supplied is inserted into the appropriate slot, taking care to ensure correct
positioning.
The arrow indicates the direction of travel.
3 INSTALLATION
perimeter
seal
